A shade sail attachment, short version

This shade sail fastener is designed for concrete or wooden walls, depending on the option chosen. It allows you to attach one of the corners of your shade sail to the wall of your house.

Short stainless steel shade sail fastener

This bracket allows you to fix a corner of your shade sail to a wall. Made of 316 stainless steel, it guarantees strength and durability. It leaves a gap of 25 to 35 cm between the fixing point and the shade sail. The stainless steel turnbuckle is only recommended in the case of a roller sail installation (on the corner of the roller).

Type of attachment: Wall mounted

Range: 25 to 35 cm (this distance includes the heights of the eyelet and the carabiner supplied with the sail)

Weight: 200g

Material: 316 stainless steel

Warranty: 2 years

Contents of the bracket

Depending on the option chosen, the adjustable stainless steel turnbuckle comes with :

Concrete wall anchor, python eye
Concrete version: 1 expansion plug + 1 piton
Separator
Wooden wall anchor, with a bridge
Wooden version: 1 bridge + 4 screws

Depending on your choice of installation, you will need additional products to fix your patio cover

Installation of the shade sail fastener

For the concrete version:
- Drilling diameter: 14mm
- Drilling depth: 80mm

Anchors for solid or hollow materials:
We have selected the PRIMA plug from SPITZ, a world leader in the fastening industry. This plug is suitable for solid and hollow walls.
The expansion technique is well proven and provides full satisfaction in its use. We recommend to follow the different installation steps of this anchor (see sketch).

Before inserting the anchor into the hole, it is important to make sure that the anchor can be fully inserted into a hole the size of the anchor.

The hole should not be too large, otherwise the plug will not expand in the substrate, as it will turn on itself in the hole.

Fonctionnement cheville à expansion
The fixings should always be in line with the diagonals or medians of the shade sail
Axes de tension d'une voile d'ombrage

Our users' opinion

What about discovering other products?

Questions
Answers

The rigging screw has a tension range of 27-35cm depending on the setting. Its travel is only 8cm. It is not recommended as a binding for sails without a furler.
